Creating scientific electronics to meet the needs of the scientific community.
9kV bipolar MOSFET switch circuit board
High-Voltage Switches
We have several off-the-shelf high-voltage switch designs available, up to 20 kV. We offer polarized and bipolar switches. Most designs include slew rate adjustment. Bipolar switch design can be extended to produce high-speed, high-voltage 3-state switches or n-state multiplexors. We also offer GaN FET based complementary switch pairs for e.g. Bradbury-Neilson gate drivers. We can design custom options to meet most any needs.
Bespoke Designs
We offer very reasonable pricing for custom electronics design. If you require something special, let us know.
Backplane for multichannel HV power supply
Raspberry Pi headers
We also offer Raspberry Pi headers. These relatively simple PCBs allow a Raspberry Pi to be connected to a PCIe connector. We offer several options, including I2C or SPI based GPIO extenders, and DACs to easily incorporate analog outputs. Use the button below to request a quote based on your needs.
PCIe64 PCB for Raspberry Pi with 16-bit GPIO extender
